Luminar 4030
In‑Line Free Space AOTF-NIR Spectrometer
Rear View of the Luminar 4030 NIR Spectrometer
Rear View of the Luminar 4030 NIR Spectrometer
The Luminar 4030 is designed for continuous in‑line or at‑line analysis in demanding production environments. Operating in free‑space mode with our AOTF‑based NIR technology, the 4030 delivers rapid, non‑destructive measurements with laboratory‑grade accuracy. Its stainless‑steel enclosure and fixed‑distance mounting allow the transmitted beam to reflect from the sample for optimal analysis, ensuring consistent, reliable performance in harsh process conditions.
Designed for direct integration into a production line, the 4030 can be mounted on a blender, pipe, or over a conveyor to monitor product flow in real time. The integrated system provides exceptional signal‑to‑noise ratio and ultra‑high‑speed scanning, enabling continuous analysis for accurate process control. It supports in‑line measurement of key parameters including ash, moisture, and protein content in food, as well as applications such as blending uniformity, fluidized bed drying performance, and tobacco analysis.
Product Information Request
Technical Specification
| Spectral Range Options | 850-1700 nm, 900-1800 nm, 1100-2300 nm (standard) |
| Measurement Modes | Diffuse Reflection |
| Spectral Resolution | 2-10 nm |
| Wavelength Accuracy | ± 0.5 nm |
| Wavelength Repeatability | ± 0.01 nm |
| Wavelength Increment | Software Selectable 1-10 nm |
| Ambient Light Rejection | > 106 |
| S/N at 70% Range | < 30μabs in reflectance and transmission, for<5 seconds integration time |
| Wavelength Access Time | < 66 μsec |
| Photometric Range | 3.5 AU |
| Linearity | Better than 0.15% |
| Signal Digitalization | 16-bit A/D (1 part in 65,536) |
| Sampling Speed | 16,000 wavelength/sec |
| Sampling Distance | 40 mm (or 65 mm with Ø10 mm Sample Area) |
| Diagnostic | 10 Built-in monitoring sensors |
| Power Requirements | 12VDC, (24VDC special order), 90Watts, 110VAC 60Hz, 220VAC 50Hz |
| Cooling Options | Fan-cooled, Vortex-cooled |
| Communication | Wireless, OPC UA, Modbus (Serial or TCP), I/O with 4-20mA, TCP/IP Ethernet |
| Enclosure (W x H x D) | 300 mm x 256 mm x 145 mm Stainless Steel NEMA 4X; Explosion-proof options available |
Key Measurement Capabilities
The Luminar 4030 provides real‑time, in‑line measurement of key chemical and physical properties directly within your production process, helping customers make fast decisions, maintain stronger process control, and deliver more consistent product quality.
Key parameters measured include:
Food Quality Control — measuring ash, moisture, and protein content in food
Blending Uniformity — real‑time monitoring of blend homogeneity during mixing operations
Fluidized Bed Drying Process — measuring moisture content during drying
Tablet Analysis — On‑line measurement of coating thickness and uniformity
Accessories / Options
Brimrose designs and builds custom mounting assemblies for easy installation of the Luminar 4030 in our customers’ manufacturing and lab facilities. These assemblies ensure stable, repeatable positioning at the required fixed distance and optimize integration into existing equipment, reducing installation time and minimizing disruption to production workflows.
Mounting Options
Tri-clamp Mount
Standard or Custom-Built Mounting Plates
Lab Stand with Rotating Sample Cup
Analog Lab Stand
